E520A
Parameters
Demonstration
Video
| E520A |
| SIZE:562x488MM |
| L:1000MM/12.24KG,2000MM/20.85KG,3000MM/29.78KG,4000MM/38.59KG |
| TUBES1:Φ50X3.0MM |
| TUBES2:Φ38X2.0MM |
| TUBES3:Φ38X2.0MM |
| TUBES4:Φ25X2.0MM |
| TUBES5:Φ50X3.0MM |
| TUBES6:Φ25X2.0MM |
| TUBES7:Φ50X3.0MM |
| Span in meter(m) | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
| Total load in(kg) | 1345 | 1218 | 1088 | 967 | 903 | 845 | 783 | 743 | 713.2 | 684 | 662 | 637 | 608 | 554 | 422 |
| Distrib.load in(kg/m) | 737.5 | 450 | 283.2 | 195.6 | 157.1 | 125.1 | 104 | 87.2 | 74.3 | 63.5 | 56.6 | 51.4 | 42.8 | 35.9 | 27.3 |
E520A
E520A
