E1680A
Parameters
Demonstration
Video
| Span in meter(m) | 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 | 25 |
| Total load in(kg) | 5000 | 4852 | 4648 | 4510 | 4392 | 4258 | 4110 | 3993 | 3896 | 3751 | 3600 |
| Distrib.load in(kg/m) | 333.3 | 303.3 | 273.4 | 250.6 | 231.2 | 212.9 | 195.7 | 181.5 | 169.4 | 156.3 | 144.0 |
| 26 | 27 | 28 | 29 | 30 | 31 | 32 | 33 | 34 | 35 | 36 | 37 | 38 | 39 | 40 | 41 | 42 |
| 3489 | 3222 | 2950 | 2711 | 2501 | 2316 | 2221 | 2006 | 1830 | 1640 | 1560 | 1480 | 1370 | 1290 | 1120 | 950 | 740 |
| 134.2 | 119.3 | 105.4 | 93.5 | 83.4 | 74.7 | 69.4 | 60.8 | 53.8 | 46.9 | 43.3 | 40.0 | 36.1 | 33.1 | 28.0 | 23.2 | 17.6 |
E1680A
E1680A
